機型
Model
|
單位
Unit
|
TZSW-1210
|
TZSW-1220
|
TZSW-2210A
|
TZSW-1210S
|
TZSW-1220S
|
TZSW-2210AS
|
| 溫控范圍Control range |
℃
|
50-200
|
| 溫控精度 Temp control accuracy |
℃
|
±1
|
| 溫控方式Temp control method |
|
雙組P.I.D演算(Proportional integral derlvative)
|
| 電源 Power |
|
3 220V/380V 50HZ/60HZ(or other)或其他
|
| 傳熱媒體Medium |
|
油 Oil
|
| 冷卻方式Cooling method |
|
直接冷卻Directcooling
|
簡介冷卻Indirectcooling
|
| 加熱能量Heating capacity |
KW
|
9
|
9
|
9+9
|
| 泵浦馬力Pump power |
HP
|
1
|
2
|
1+1
|
| 大泵浦流量Max.Pump flow |
L/min
|
153
|
232
|
153+153
|
| 系統壓力System pressure |
Kg/cm2
|
4
|
6
|
4+4
|
| 大電力消耗Power supply |
Kw
|
9.75
|
10.5
|
19.5
|
| 冷卻水配管Cooling water pipe |
Inch
|
1/2" PT
|
| 熱油配管Hot oil pipeing |
Inch
|
3/8" PT*4(or other)或其他
|
| 外形尺寸L*W*H |
Cm
|
60*28*55 68*45*60 60*35*68
|
| 重量Weight |
Kg
|
50
|
65
|
100
|
| 產品規格若有變更，恕不另行通知。Please excuse for not note if some specifications of products are changed. |
|
